Description

PGVIP - auto failover service from master to standby PostgreSQL database using virtual (floating) IP address

The service is installed on one server, which is a single point of failure (example, nginx proxy), or on any two servers (hereinafter referred to as web servers). There is no need to install anything on the database servers; the web server connects to them via ssh and executes commands from the configuration file. Administrator performs initial setup of the standby database and reverse switch manually.

Failover schemas:
for one web server

for multiple web servers

Technically, the PGVIP service is implemented as a wrapper that executes operating system commands from a configuration file. It was originally developed as a bash script, then rewritten in C language.

Conditions underling the development:

small projects in which installing a cluster (for example, Patroni) is impractical
no requirements for a standby database
the administrator manually creates a standby database and after failover switches it back using standard tools (pg_basebackup)
all commands are customizable; the administrator can run any command on the command line to check it
direct connection to the master database without intermediate layers, VIP is activated (up) on the network interface with a physical address
compilation with one command without configuration and libraries
actions are performed only depending on the current state, this allows to avoid saving information about the state of databases and not synchronizing web servers

more details in the section Important qualities

Main actions performed by the pgvip service:

checking the availability of the master database and the lag of the standby database, the status of the virtual IP address (up/down)
managing a virtual IP address, running a script to automatically turn it off (necessary if the connection is lost)
activation (promotion) of a standby database and transfer of a virtual IP address

more details in the section Actions

Status (pgvip status)

[root@web-server ~]# pgvip status
status: SUCCESS (duration: 0 00:00:32)

+---------+--------------+-------------------------+---------------+---------------+
| Role    | IP address   | Database state          | 192.168.56.10 | VIP auto down |
+---------+--------------+-------------------------+---------------+---------------+
| master  | 192.168.56.1 | read-write              | up on enp0s3  | executing     |
| standby | 192.168.56.2 | in recovery, lag 0 min. | down          | executing     |
+---------+--------------+-------------------------+---------------+---------------+


[root@web-server ~]# pgvip status
status: ERROR (duration: 0 00:00:14, cause: master db is not read-write)

+---------+--------------+-------------------------+---------------+---------------+
| Role    | IP address   | Database state          | 192.168.56.10 | VIP auto down |
+---------+--------------+-------------------------+---------------+---------------+
| master  | 192.168.56.1 | not available           | not available | not available |
| standby | 192.168.56.2 | in recovery, lag 0 min. | down          | executing     |
+---------+--------------+-------------------------+---------------+---------------+


[root@web-server ~]# pgvip status
status: STANDBY_PROMOTED (duration: 0 00:00:06)

+---------+--------------+----------------+---------------+---------------+
| Role    | IP address   | Database state | 192.168.56.10 | VIP auto down |
+---------+--------------+----------------+---------------+---------------+
| master  | 192.168.56.1 | not available  | not available | not available |
| standby | 192.168.56.2 | read-write     | up on enp0s3  | executing     |
+---------+--------------+----------------+---------------+---------------+

System journal (journalctl -fu pgvip or tail -f /var/log/pgsuite/pgvip.log)

[root@web-server ~]# journalctl -fu pgvip
Feb 08 09:49:17 web-server systemd[1]: Started pgvip (PostgreSQL master-standby auto failover).
Feb 08 09:49:17 web-server systemd[1]: Starting pgvip (PostgreSQL master-standby auto failover)...
Feb 08 09:49:17 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      thread started, thread_id: 2718
Feb 08 09:49:17 web-server pgvip[2713]: INFO  ADMINISTRATION       thread started, thread_id: 2719
Feb 08 09:49:17 web-server pgvip[2713]: INFO  ADMINISTRATION       binded to unix socket "/tmp/.s.PGVIP.0"
Feb 08 09:49:17 web-server pgvip[2713]: INFO  ADMINISTRATION       listening
Feb 08 09:49:17 web-server pgvip[2713]: INFO  CHECKER_MASTER_DB    thread started, thread_id: 2714
Feb 08 09:49:17 web-server pgvip[2713]: INFO  CHECKER_MASTER_VIP   thread started, thread_id: 2715
Feb 08 09:49:17 web-server pgvip[2713]: INFO  CHECKER_STANDBY_DB   thread started, thread_id: 2716
Feb 08 09:49:17 web-server pgvip[2713]: INFO  CHECKER_STANDBY_VIP  thread started, thread_id: 2717
...
Feb 08 09:50:15 web-server pgvip[2713]: WARN  CHECKER_MASTER_DB    PGSUITE-905 OS command executed with error (errno: 124)
Feb 08 09:50:15 web-server pgvip[2713]: WARN  CHECKER_MASTER_DB    command:
Feb 08 09:50:15 web-server pgvip[2713]: WARN  CHECKER_MASTER_DB    timeout 5 ssh 192.168.56.1 "su - postgres -c "psql -Aqtc 'select pg_is_in_recovery() or pg_current_xact_id() is null, extract(epoch from now()-pg_last_xact_replay_timestamp())'""
Feb 08 09:50:15 web-server pgvip[2713]: WARN  CHECKER_MASTER_DB    output:
Feb 08 09:50:15 web-server pgvip[2713]: WARN  CHECKER_MASTER_DB
Feb 08 09:50:15 web-server pgvip[2713]: WARN  CHECKER_MASTER_VIP   PGSUITE-905 OS command executed with error (errno: 124)
Feb 08 09:50:15 web-server pgvip[2713]: WARN  CHECKER_MASTER_VIP   command:
Feb 08 09:50:15 web-server pgvip[2713]: WARN  CHECKER_MASTER_VIP   timeout 5 ssh 192.168.56.1 "flock /tmp/pgvip.time -c 'date +%s > /tmp/pgvip.time' ; flock -n /tmp/pgvip.vip_auto_down -c '' ; echo -n $?, ; ip address show | awk '/ inet 192.168.56.10\// {print $NF}'"
Feb 08 09:50:15 web-server pgvip[2713]: WARN  CHECKER_MASTER_VIP   output:
Feb 08 09:50:15 web-server pgvip[2713]: WARN  CHECKER_MASTER_VIP
...
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      executing action "action_standby_db_promote"
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      condition: (time_now()-status.value_time)>g_time_standby_promote_delay_int && status.master_db_state!=G_DB_STATE_READ_WRITE && status.standby_db_state==G_DB_STATE_IN_RECOVERY && status.standby_db_lag<=g_time_standby_allowable_lag_int
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      status: ERROR (duration: 0 00:00:41, cause: master db is not read-write)
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      +---------+--------------+-------------------------+---------------+---------------+
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      | Role    | IP address   | Database state          | 192.168.56.10 | VIP auto down |
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      +---------+--------------+-------------------------+---------------+---------------+
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      | master  | 192.168.56.1 | not available           | not available | not available |
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      | standby | 192.168.56.2 | in recovery, lag 0 min. | down          | executing     |
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      +---------+--------------+-------------------------+---------------+---------------+
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      executing command:
Feb 08 09:50:56 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      timeout 5 ssh 192.168.56.1 "ip address del 192.168.56.10/24 dev `ip address show | awk '/ inet 192.168.56.10\// {print $NF}'`"
Feb 08 09:50:59 web-server pgvip[2713]: WARN  ACTION_EXECUTOR      PGSUITE-905 OS command executed with error (errno: 255)
Feb 08 09:50:59 web-server pgvip[2713]: WARN  ACTION_EXECUTOR      output:
Feb 08 09:50:59 web-server pgvip[2713]: WARN  ACTION_EXECUTOR
Feb 08 09:50:59 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      executing command:
Feb 08 09:50:59 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      timeout 5 ssh 192.168.56.2 "su - postgres -c "\$(pg_config --bindir)/pg_ctl promote -W -D \$(psql -Aqtc 'show data_directory')""
Feb 08 09:50:59 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      output:
Feb 08 09:50:59 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      server promoting
Feb 08 09:50:59 web-server pgvip[2713]: INFO  ACTION_EXECUTOR
Feb 08 09:50:59 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      command executed successfully
Feb 08 09:50:59 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      executing command:
Feb 08 09:50:59 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      timeout 5 ssh 192.168.56.2 "ip address add 192.168.56.10/24 dev `ip address show | awk '/ inet 192.168.56.2\// {print $NF}'`"
Feb 08 09:51:00 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      output:
Feb 08 09:51:00 web-server pgvip[2713]: INFO  ACTION_EXECUTOR
Feb 08 09:51:00 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      command executed successfully
Feb 08 09:51:00 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      action "action_standby_db_promote" executed successfully
...
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      executing action "action_master_db_break"
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      condition: status.master_db_state==G_DB_STATE_READ_WRITE && status.standby_db_state==G_DB_STATE_READ_WRITE
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      status: STANDBY_PROMOTED (duration: 0 00:01:25)
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      +---------+--------------+----------------+---------------+---------------+
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      | Role    | IP address   | Database state | 192.168.56.10 | VIP auto down |
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      +---------+--------------+----------------+---------------+---------------+
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      | master  | 192.168.56.1 | read-write     | down          | executing     |
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      | standby | 192.168.56.2 | read-write     | up on enp0s3  | executing     |
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      +---------+--------------+----------------+---------------+---------------+
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      executing command:
Feb 08 09:52:29 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      timeout 5 ssh 192.168.56.1 "su - postgres -c "psql -c 'alter system set listen_addresses=pgvip_broken'" ; ps -e | awk '$4=="postmaster" || $4=="postgres" {print $1}' | xargs -r kill -9"
Feb 08 09:52:30 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      output:
Feb 08 09:52:30 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      ALTER SYSTEM
Feb 08 09:52:30 web-server pgvip[2713]: INFO  ACTION_EXECUTOR
Feb 08 09:52:30 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      command executed successfully
Feb 08 09:52:30 web-server pgvip[2713]: INFO  ACTION_EXECUTOR      action "action_master_db_break" executed successfully

[root@web-server ~]# mkdir /tmp/pgvip ; cd /tmp/pgvip

[root@web-server /tmp/pgvip]# curl -Os https://pgvip.org/files/download/pgvip.tar

[root@web-server /tmp/pgvip]# tar -xf pgvip.tar

[root@web-server /tmp/pgvip]# make install ip_master=192.168.56.1 ip_standby=192.168.56.2 ip_virtual=192.168.56.10 subnet_mask=24
# Configuration
if [ -z "24" ] ; then echo -e '
Usage with parameters: make install ip_master=[ip_master] ip_standby=[ip_standby] ip_virtual=[ip_virtual] subnet_mask=[subnet_mask]
Example: make install ip_master=192.168.56.1 ip_standby=192.168.56.2 ip_virtual=192.168.56.10 subnet_mask=24' ; exit 1; fi
if [ -e /etc/pgsuite/pgvip.conf ]   ; then echo -e '
Configuration file /etc/pgsuite/pgvip.conf already exists, change it' ; exit 1; fi
cp pgvip.conf /etc/pgsuite/pgvip.conf
sed -i "s/[ip_master]/192.168.56.1/;s/[ip_standby]/192.168.56.2/;s/[ip_virtual]/192.168.56.10/;s/[subnet_mask]/24/" /etc/pgsuite/pgvip.conf
# Service
if [ -e /etc/systemd/system/pgvip.service ] ; then echo -e '
Service file /etc/systemd/system/pgvip.service already exists, change it' ; exit 1; fi
cp pgvip.service /etc/systemd/system/pgvip.service
rm -f /usr/bin/pgvip
cp pgvip /usr/bin/pgvip
systemctl daemon-reload
echo -e '
pgvip service has been successfully created.
Use command "systemctl --now enable pgvip" to enable and start service,
"journalctl -fu pgvip" to view the journal'

pgvip service has been successfully created.
Use command "systemctl --now enable pgvip" to enable and start service,
"journalctl -fu pgvip" to view the journal

[root@web-server pgvip]# systemctl --now enable pgvip
Created symlink from /etc/systemd/system/multi-user.target.wants/pgvip.service to /etc/systemd/system/pgvip.service.

[root@web-server pgvip]# systemctl status pgvip
● pgvip.service - pgvip (PostgreSQL master-standby auto failover)
   Loaded: loaded (/etc/systemd/system/pgvip.service; enabled; vendor preset: disabled)
   Active: active (running) since Fri 2025-02-15 10:51:33 EST; 2s ago
 Main PID: 1546 (pgvip)
   CGroup: /system.slice/pgvip.service
           ├─1546 /usr/bin/pgvip execute
           ├─1553 timeout 5 ssh 192.168.56.1 su - postgres -c "psql -Aqtc 'select pg_is_in_recovery() or pg_current_xact_id() is null, extract(epoch from now()-pg_last_xact_replay_timestamp())'"
           ├─1554 timeout 5 ssh 192.168.56.1 flock /tmp/pgvip.time -c 'date +%s > /tmp/pgvip.time' ; flock -n /tmp/pgvip.vip_auto_down -c '' ; echo -n $?, ; ip address show | awk '/ inet 192.168.5...
           ├─1555 timeout 5 ssh 192.168.56.2 su - postgres -c "psql -Aqtc 'select pg_is_in_recovery() or pg_current_xact_id() is null, extract(epoch from now()-pg_last_xact_replay_timestamp())'"
           ├─1556 timeout 5 ssh 192.168.56.2 flock /tmp/pgvip.time -c 'date +%s > /tmp/pgvip.time' ; flock -n /tmp/pgvip.vip_auto_down -c '' ; echo -n $?, ; ip address show | awk '/ inet 192.168.5...
           ├─1557 ssh 192.168.56.1 su - postgres -c "psql -Aqtc 'select pg_is_in_recovery() or pg_current_xact_id() is null, extract(epoch from now()-pg_last_xact_replay_timestamp())'"
           ├─1558 ssh 192.168.56.1 flock /tmp/pgvip.time -c 'date +%s > /tmp/pgvip.time' ; flock -n /tmp/pgvip.vip_auto_down -c '' ; echo -n $?, ; ip address show | awk '/ inet 192.168.56.10// {p...
           ├─1559 ssh 192.168.56.2 su - postgres -c "psql -Aqtc 'select pg_is_in_recovery() or pg_current_xact_id() is null, extract(epoch from now()-pg_last_xact_replay_timestamp())'"
           └─1560 ssh 192.168.56.2 flock /tmp/pgvip.time -c 'date +%s > /tmp/pgvip.time' ; flock -n /tmp/pgvip.vip_auto_down -c '' ; echo -n $?, ; ip address show | awk '/ inet 192.168.56.10// {p...

Feb 15 10:51:33 web-server systemd[1]: Started pgvip (PostgreSQL master-standby auto failover).
Feb 15 10:51:33 web-server systemd[1]: Starting pgvip (PostgreSQL master-standby auto failover)...
Feb 15 10:51:33 web-server pgvip[1546]: INFO  ACTION_EXECUTOR      thread started, thread_id: 1551
Feb 15 10:51:33 web-server pgvip[1546]: INFO  ADMINISTRATION       thread started, thread_id: 1552
Feb 15 10:51:33 web-server pgvip[1546]: INFO  ADMINISTRATION       binded to unix socket "/tmp/.s.PGVIP.0"
Feb 15 10:51:33 web-server pgvip[1546]: INFO  ADMINISTRATION       listening
Feb 15 10:51:33 web-server pgvip[1546]: INFO  CHECKER_MASTER_DB    thread started, thread_id: 1547
Feb 15 10:51:33 web-server pgvip[1546]: INFO  CHECKER_MASTER_VIP   thread started, thread_id: 1548
Feb 15 10:51:33 web-server pgvip[1546]: INFO  CHECKER_STANDBY_DB   thread started, thread_id: 1549
Feb 15 10:51:33 web-server pgvip[1546]: INFO  CHECKER_STANDBY_VIP  thread started, thread_id: 1550

[root@web-server pgvip]# pgvip status
status: SUCCESS (duration: 0 00:00:00)

+---------+--------------+-------------------------+---------------+---------------+
| Role    | IP address   | Database state          | 192.168.56.10 | VIP auto down |
+---------+--------------+-------------------------+---------------+---------------+
| master  | 192.168.56.1 | read-write              | up on enp0s3  | executing     |
| standby | 192.168.56.2 | in recovery, lag 0 min. | down          | executing     |
+---------+--------------+-------------------------+---------------+---------------+

[root@web-server pgvip]# journalctl -fu pgvip
Feb 15 10:54:50 web-server pgvip[1767]: INFO  ADMINISTRATION       connection accepted
Feb 15 10:54:50 web-server pgvip[1767]: INFO  ADMINISTRATION       received command "status"
Feb 15 10:54:50 web-server pgvip[1767]: INFO  ADMINISTRATION       info sent
Feb 15 10:54:50 web-server pgvip[1767]: INFO  ACTION_EXECUTOR      output:
Feb 15 10:54:50 web-server pgvip[1767]: INFO  ACTION_EXECUTOR
Feb 15 10:54:50 web-server pgvip[1767]: INFO  ACTION_EXECUTOR      command executed successfully
Feb 15 10:54:50 web-server pgvip[1767]: INFO  ACTION_EXECUTOR      action "action_master_vip_up" executed successfully
Feb 15 10:54:52 web-server pgvip[1767]: INFO  ADMINISTRATION       connection accepted
Feb 15 10:54:52 web-server pgvip[1767]: INFO  ADMINISTRATION       received command "status"
Feb 15 10:54:52 web-server pgvip[1767]: INFO  ADMINISTRATION       info sent

[root@web-server pgvip]# pgvip show config
PGVIP is a PostgreSQL master-standby auto failover service via a virtual IP address
version 25.1.1, linux 64 bits

Runtime configuration

IP addresses
  ip_master:      192.168.56.1
  ip_standby:     192.168.56.2
  ip_virtual:     192.168.56.10
  ip_subnet_mask: 24

OS command templates
  command_ssh:                   timeout ${time_command_ssh_timeout} ssh ${ip} "${command}"
  command_db_state:              su - postgres -c "psql -Aqtc 'select pg_is_in_recovery() or pg_current_xact_id() is null, extract(epoch from now()-pg_last_xact_replay_timestamp())'"
  command_db_break:              su - postgres -c "psql -c 'alter system set listen_addresses=pgvip_broken'" ; ps -e | awk '$4=="postmaster" || $4=="postgres" {print $1}' | xargs -r kill -9
  command_db_promote:            su - postgres -c "$(pg_config --bindir)/pg_ctl promote -W -D $(psql -Aqtc 'show data_directory')"
  command_ifname:                ip address show | awk '/ inet ${ip}// {print $NF}'
  command_vip_state:             flock /tmp/pgvip.time -c 'date +%s > /tmp/pgvip.time' ; flock -n /tmp/pgvip.vip_auto_down -c '' ; echo -n $?, ; ${command_ifname}
  command_vip_up:                ip address add ${ip_virtual}/${ip_subnet_mask} dev `${command_ifname}`
  command_vip_down:              ip address del ${ip_virtual}/${ip_subnet_mask} dev `${command_ifname}`
  command_vip_auto_down_script:  delta=0 ; while [ $delta -lt ${time_vip_auto_down_duration} ] ; do set -x; date +%Y-%m-%d_%H:%M:%S ; sleep ${time_check_interval} ; delta=$(($(date +%s)-$(flock /tmp/pgvip.time cat /tmp/pgvip.time))) ; if [ $delta -gt ${time_vip_auto_down_timeout} ] ; then ${command_vip_down} ; fi ; done
  command_vip_auto_down_execute: flock -w 1 /tmp/pgvip.vip_auto_down -c "${command_vip_auto_down_script} > /dev/null 2>&1 &"

Timings in seconds
  time_command_ssh_timeout:          5
  time_check_interval:               5
  time_check_not_available_delay:   15
  time_standby_allowable_lag:      300
  time_standby_promote_delay:       30
  time_vip_auto_down_timeout:       30
  time_vip_auto_down_duration:     600
  time_monitoring_interval:         15

Generated OS commands
  command_master_db_state:               timeout 5 ssh 192.168.56.1 "su - postgres -c "psql -Aqtc 'select pg_is_in_recovery() or pg_current_xact_id() is null, extract(epoch from now()-pg_last_xact_replay_timestamp())'""
  command_master_db_break:               timeout 5 ssh 192.168.56.1 "su - postgres -c "psql -c 'alter system set listen_addresses=pgvip_broken'" ; ps -e | awk '$4=="postmaster" || $4=="postgres" {print $1}' | xargs -r kill -9"
  command_master_vip_state:              timeout 5 ssh 192.168.56.1 "flock /tmp/pgvip.time -c 'date +%s > /tmp/pgvip.time' ; flock -n /tmp/pgvip.vip_auto_down -c '' ; echo -n $?, ; ip address show | awk '/ inet 192.168.56.10\// {print $NF}'"
  command_master_vip_up:                 timeout 5 ssh 192.168.56.1 "ip address add 192.168.56.10/24 dev `ip address show | awk '/ inet 192.168.56.1\// {print $NF}'`"
  command_master_vip_down:               timeout 5 ssh 192.168.56.1 "ip address del 192.168.56.10/24 dev `ip address show | awk '/ inet 192.168.56.10\// {print $NF}'`"
  command_master_vip_auto_down_execute:  timeout 5 ssh 192.168.56.1 "flock -w 1 /tmp/pgvip.vip_auto_down -c "delta=0 ; while [ \$delta -lt 600 ] ; do set -x; date +%Y-%m-%d_%H:%M:%S ; sleep 5 ; delta=\$((\$(date +%s)-\$(flock /tmp/pgvip.time cat /tmp/pgvip.time))) ; if [ \$delta -gt 30 ] ; then ip address del 192.168.56.10/24 dev \`ip address show | awk '/ inet 192.168.56.10\\// {print \$NF}'\` ; fi ; done > /dev/null 2>&1 &""
  command_standby_db_state:              timeout 5 ssh 192.168.56.2 "su - postgres -c "psql -Aqtc 'select pg_is_in_recovery() or pg_current_xact_id() is null, extract(epoch from now()-pg_last_xact_replay_timestamp())'""
  command_standby_db_promote:            timeout 5 ssh 192.168.56.2 "su - postgres -c "\$(pg_config --bindir)/pg_ctl promote -W -D \$(psql -Aqtc 'show data_directory')""
  command_standby_vip_state:             timeout 5 ssh 192.168.56.2 "flock /tmp/pgvip.time -c 'date +%s > /tmp/pgvip.time' ; flock -n /tmp/pgvip.vip_auto_down -c '' ; echo -n $?, ; ip address show | awk '/ inet 192.168.56.10\// {print $NF}'"
  command_standby_vip_up:                timeout 5 ssh 192.168.56.2 "ip address add 192.168.56.10/24 dev `ip address show | awk '/ inet 192.168.56.2\// {print $NF}'`"
  command_standby_vip_down:              timeout 5 ssh 192.168.56.2 "ip address del 192.168.56.10/24 dev `ip address show | awk '/ inet 192.168.56.10\// {print $NF}'`"
  command_standby_vip_auto_down_execute: timeout 5 ssh 192.168.56.2 "flock -w 1 /tmp/pgvip.vip_auto_down -c "delta=0 ; while [ \$delta -lt 600 ] ; do set -x; date +%Y-%m-%d_%H:%M:%S ; sleep 5 ; delta=\$((\$(date +%s)-\$(flock /tmp/pgvip.time cat /tmp/pgvip.time))) ; if [ \$delta -gt 30 ] ; then ip address del 192.168.56.10/24 dev \`ip address show | awk '/ inet 192.168.56.10\\// {print \$NF}'\` ; fi ; done > /dev/null 2>&1 &""

[root@web-server /tmp/pgvip]#

Patroni is a cluster and is better in every aspect than PGVIP, which performs a one-time switchover and is not a cluster.

However, may be considered using PGVIP instead of Patroni in the following situations:

no database administrator (DBA), entry-level system administrator (junior)
unacceptability of transaction data loss when using non-synchronous standby, the need to manually transfer data after failover
standby database with a lag (recovery_min_apply_delay parameter)
applying WAL segment files from backup to standby (restore_command parameter) without creating a replication slot on master
direct network connection to the database without using intermediate levels (HAProxy)
lack of 3 physical devices required to create a quorum from etcd/Zookeeper/Consul
lower computing power of the standby server compared to the master

It is possible to configure Keepalived to auto-switch master-standby.

Keepalived transfers the virtual IP address based on service availability, so different situations need to be considered when configuring:

standby database was activated (promoted), after the reboot the master server booted first
loss of connection between servers
large lag standby
and the like

The setup requires complex logic and additional scripts. Some actions are performed by Keepalived, some by scripts. Parameters (for example, IP addresses) are specified in various places: keepalived.conf file and scripts. Because of this, it is quite easy to miss something or make a mistake.

PGVIP performs actions based on information from the master and standby servers. Parametrs in one configuration file that contains all commands.

When PGVIP installed on one web server, split-brain is impossible by definition.

When installed on two web servers, split-brain is unlikely, because when two databases are detected from any web server in read-write state, the master database stops without the ability to start:

listen_addresses configuration parameter is set to an invalid value
postmaster and postgres processes terminate in the operating system

Any standby database - there are no requirements for a standby database. The standby database may have a lag (recovery_min_apply_delay parameter), using WAL segment files from backup (restore_command parameter) without creating a replication slot
Direct connection - the virtual IP address is activated (up) on the network interface with the physical address, connection to the database occurs without intermediate layers
No DBA required - installation and configuration can be performed by a system administrator at the junior level, modification - by a system administrator at the middle level
Easy installation - installation consists of two operations: setting up ssh keys and executing the make install command
Making is optional - making has already been completed, because does not depend on Linux versions and does not require additional libraries. If necessary, executed with one gcc command
All commands are customizable - pgvip service only executes operating system commands from the configuration file. To check, the administrator can execute any in command line
Obvious action log - When an action is executed, printed to log: action name, condition, status (pgvip status), OS command with output. The action name and condition are actual C code snippets from the action.c file, obtained by the macro #define #[name]
Actions without history - actions are performed only depending on the current status, it is possible not to save information about the state of databases and do not synchronize web servers

Large projects - use on large projects is not recommended due PGVIP is not a cluster and requires manual recovery. Large projects involve DBA who will set up the cluster (for example, Patroni)
Delay before switching - In case of temporary unavailability of the master server (for example, during a reboot), there is a delay before activation standby database
Manual setup and recovery - administrator performs initial setup of the standby database and reverse switch manually, usually pg_basebackup is used
Linux - only Linux operating system is supported
Using WEB servers - installation is performed on web servers, not on database servers

PGVIP

Auto failover to standby PostgreSQL server

PGVIP

About
